Code: 6047720
Loading...
| Support spacing 1.5 m | 1,35 kN/m | Connector version | Integrated connector |
|---|---|---|---|
| Dimension y | 450 mm | Load test type according to IEC 61537 | Type II |
| Magnetic shield insulation with cover | 50 dB | Magnetic shield insulation without cover | 20 dB |
| Mounting perforation in base | yes | NATO hole pattern | no |
| NEMA load class | 8AA | Plate thickness | 1 mm |
| Type of connector, cable support system | Click fastening | Usable length | 3000 mm |
| With cover | no | Dimension x | 400 mm |
| Base perforation | 1.3 | Support spacing 1.0 m | 2,1 kN/m |
| Dimension t | 300 mm | Colour | zinc |
| Width | 500 mm | Wide-span version | no |
| Usable cross-section | 298 cm² | Support spacing 2.5 m | 0,6 kN/m |
| Support spacing 2.0 m | 0,9 kN/m | Side perforation | yes |
| Rustproof steel, pickled | no | Maintain electrical functions | no |
| Height | 2 in | Dimension B | 500 mm |
| CO₂ Footprint (GWP) Cradle-to-Gate | 12,0516 kg CO₂e / 1 Meter | Surface | Hot-dip galvanised |
| Material | Steel | Length | 10 ft |
| Dimension | 60x500x3050 |
