Code: 6059032
Loading...
| Wide-span version | no | Sprinkler system use | yes |
|---|---|---|---|
| Dimension x | 496 mm | With cover | no |
| Usable length | 3000 mm | Type of connector, cable support system | Click fastening |
| Support spacing 1.5 m | 1,5 kN/m | NATO hole pattern | no |
| Mounting perforation in base | yes | Magnetic shield insulation without cover | 20 dB |
| Magnetic shield insulation with cover | 50 dB | Load test type according to IEC 61537 | Type II |
| Dimension y | 562 mm | Connector version | Integrated connector |
| Plate thickness | 1 mm | Width | 600 mm |
| Colour | zinc | Usable cross-section | 35800 mm² |
| Support spacing 2.5 m | 0,7 kN/m | Support spacing 2.0 m | 1 kN/m |
| Side perforation | yes | Rustproof steel, pickled | no |
| Maintain electrical functions | no | Height | 60 mm |
| Dimension B | 600 mm | CO₂ Footprint (GWP) Cradle-to-Gate | 12,9439 kg CO₂e / 1 Meter |
| Surface | Hot-dip galvanised | Material | Steel |
| Length | 3050 mm | Dimension L | 480 mm |
| Dimension | 60x600x3050 |
