EUR (€)
Code: 6047690
Selling Units:
Mtr
Loading...
| Type of connector, cable support system | Click fastening | Dimension y | 350 mm |
|---|---|---|---|
| Load test type according to IEC 61537 | Type II | Magnetic shield insulation with cover | 50 dB |
| Magnetic shield insulation without cover | 20 dB | Mounting perforation in base | yes |
| NATO hole pattern | no | NEMA load class | 8AA |
| Support spacing 1.5 m | 1,35 kN/m | Connector version | Integrated connector |
| Usable length | 3000 mm | With cover | no |
| Dimension x | 300 mm | Base perforation | 1.3 |
| Fire protection | Maintenance of electrical function of cable-specific support structure | Support spacing 1.0 m | 2,1 kN/m |
| Dimension t | 200 mm | Rustproof steel, pickled | no |
| Dimension | 60x400x3050 | Length | 10 ft |
| Material | Steel | Surface | Hot-dip galvanised |
| CO₂ Footprint (GWP) Cradle-to-Gate | 10,3034 kg CO₂e / 1 Meter | Dimension B | 400 mm |
| Height | 60 mm | Maintain electrical functions | yes |
| Colour | zinc | Side perforation | yes |
| Support spacing 2.0 m | 0,9 kN/m | Support spacing 2.5 m | 0,6 kN/m |
| Usable cross-section | 23800 mm² | Wide-span version | no |
| Width | 16 in | Plate thickness | 1 mm |
